Submersible Septic Tank Pump| Sonho Pump|BAF Series
Need a reliable Submersible Septic Tank Pump? Sonho Pump’s BAF series handles impurities with ease. Durable stainless steel, thermal protection. Get a quote
Submersible Septic Tank Pump
Application：
-
Food market drainage and water refining tanks
-
Septic tank discharge and domestic wastewater drainage
-
Animal husbandry and livestock farm wastewater management
- Wastewater treatment plants and municipal sewage systems
-
Basement drainage and general industrial wastewater management
FEATURES：
-
Motor Protection: Built-in protection device prevents the motor from overheating or overloading.
-
Anti-Clog Design: Vortex type impeller ensures light solids pass through without blockage.
-
Durable Construction: High-strength stainless-steel motor frame, shaft, and screws; dual mechanical seals provide extended service life (for models above 3Hp).
-
Enhanced Reliability: Inner cable wires and base are upgraded with EPOXY filling for superior humidity resistance.
-
Convenience: Optional float switch available for models under 2Hp.
| Model | Power Hp (kW) |
Discharge inch |
Phase φ |
Standards | Free Passage mm |
|
|---|---|---|---|---|---|---|
| Head m | Capacity m³/min | |||||
| BAF-205 | 0.5kW | 2″ | (1φ 220v)/ 3φ | 6 | 0.14 | 35 |
| BAF-208 | 1½ (1.1) | 2″ | (1φ 220v)/ 3φ | 8 | 0.2 | 35 |
| BAF-315 | 2 (1.5) | 3″ | (1φ 220v)/ 3φ | 8 | 0.5 | 40 |
| BAF-322B | 3 (2.2) | 3″ | 3φ | 10 | 0.4 | 45 |
| BAF-337 | 5 (3.7) | 3″ | 3φ | 14 | 0.5 | 55 |
| BAF-355A | 7½ (5.5) | 3″/4″ | 3φ | 22 | 0.5 | 55 |
